Scorpion Tribunus II 14-300A ESC SBEC

TribunusII 14-300A ESC SBEC

Neuf

Airplane and Heli mode,

Stored and unstored Governor, external governor.

Data Logging, Data output port for external data logging device, such as Mikado V control / Vbar combinations. Jeti Telemetry , JLog 3 and Futaba.

ESC setup can be set by Mikado V control Radio

PC connectivity, Android connectivity ( OTG cable needed) , V link II Cable(optional) plus Diode adaptor(included) cable needed

Plus de détails

669,90 € TTC

En savoir plus

Specifications

Max Continuous Current 300 Amps
Peak Current 400Amps
Operating Voltage Range 14-61 Volts **
BEC Output voltage: 5.1V to 8.3V adjustable.
Max Continuous BEC Output 10 Amps @ 8.3 V
Peak BEC Output 30 Amps/1s @ 8.3 V
On Resistance 0.65 mOhms *2
Size 90.7mm x 50mm x 31.9mm (3.57 x 1.97 x 1.26 in)
Weight (Without Connectors) 244g (8.61 oz)
Drive frequency 8kHz - 32kHz

Included in the Box

Connection cable *2

**Using up to16s HV Lipo will not void the warranty.

Supported HvLi battery 14S total 61V **.
